Rear Steering Component P/No.s and Diagrams

ApexHunter

Well-known member
Joined
Apr 25, 2007
Messages
1,985
Location
Marysville, WA
Found this little exploded view and p/n's for rear steering components.

click

Not sure if this has already been archived. I just stumbled upon this and figured i'd better toss it up here just in case.


ApexHunter

Well-known member
Joined
Apr 25, 2007
Messages
1,985
Location
Marysville, WA


Figured i'd better upload the file to the site just in case that link dies.

Legend:

1 MB584200 RACK ASSY

2 MB584200 TIE ROD END RIGHT

2 MB584200 TIE ROD END LEFT

3 MB489785 BOOT

4 MR244529 BOOT CLAMP

5 MB489751 PUMP

6 MB489760 VALVE
