Starting to set up package deals. You can also just order individual parts from me or just have me port your head. Its totally up to you. All of these prices are for 4g63's.
Mitsu Valve packages
E-LOY Performance stainless valves
1mm over intake valves
.5mm over exhaust valves
1 set=16 valves 232.00
Super Tech Valves
1mm over intake valves
1mm over exhaust valves which are inconel(can take very high heat)
1 set=16 valves 332.00
Bronze valve guides=set of 16 72.00or4.50 each
Set of 16 valves seals=23.00
set of 32 valve locks=25.00
Super Tech single valve springs=145.00
Super Tech single valve springs with Ti retainers=335.00
Super Tech dual valve springs with spring seats and Ti retainers=415.00
Machine work is as follows, all done by Class One Performance Engines by Terry Thomas
R&R Guides and hone to ID size=88.00
Valve Job-Radius cut seats,2 angle valves as needed, mill deck surface and chamfer chamber's, finish cleaned and assembled, springs installed, seals installed, tips of valves cut to remain in specs=250.00
Line hone cam Journal's-varies by the head=75.00-100.00
All this work can be done or you can pick and choose what you want done. My porting work is 600.00. If you are going to send me your own parts they have to be quality parts and in good shape. PM me with any questions.
Mitsu Valve packages
E-LOY Performance stainless valves
1mm over intake valves
.5mm over exhaust valves
1 set=16 valves 232.00
Super Tech Valves
1mm over intake valves
1mm over exhaust valves which are inconel(can take very high heat)
1 set=16 valves 332.00
Bronze valve guides=set of 16 72.00or4.50 each
Set of 16 valves seals=23.00
set of 32 valve locks=25.00
Super Tech single valve springs=145.00
Super Tech single valve springs with Ti retainers=335.00
Super Tech dual valve springs with spring seats and Ti retainers=415.00
Machine work is as follows, all done by Class One Performance Engines by Terry Thomas
R&R Guides and hone to ID size=88.00
Valve Job-Radius cut seats,2 angle valves as needed, mill deck surface and chamfer chamber's, finish cleaned and assembled, springs installed, seals installed, tips of valves cut to remain in specs=250.00
Line hone cam Journal's-varies by the head=75.00-100.00
All this work can be done or you can pick and choose what you want done. My porting work is 600.00. If you are going to send me your own parts they have to be quality parts and in good shape. PM me with any questions.
