Milodon Vac-U-Pan Systems 85700

[tektic]

Has anyone ever tried or considered this instead of a catch can system?
click
vibrant has one too



[Mdlimy]

I have one on my car, seems to work well. Plenty of other people using them with good results. Results are very dependent on how much your exhaust flows and the velocity.

I am using the vibrant one.



[tektic]

Any smell from burning oil or the like? What are you using for a one way valve?



[EHmotorsports]

Just make sure the events you run allow it. Most racing organisations I know of have outlawed this due to fire hazards.



[mitsuturbo]

From what i understand, these work best when placed at the exhaust exit. I did something similar to this, but i ran it to the turbo intake pipe and used an oil separator that drains back to the block. Works pretty damn well.



[curtis]

I've done this a couple times... the little one way valve can be sourced from the egr system on a 5.0 fox body mustang tbird etc late 80/early 90's. Just hacksaw the tube off and you can use it as well as the valve then some rubber hose and your done. Morosos site has the explanation of how and what angle to weld these on. Seems like the tube has to be in the exhaust pipe about 3/4 of an inch.



[curtis]

15 pages of info here
