Street 88/2000

88/2000

Specs

Ownership Status
Currently Own
Year
1991
Production Number
88
Mods-Power
INTAKE:
Speed Density
JMF Intake Manifold
Nissan Q45 Throttle Body [80mm]
ETS FMIC [2.5" IC piping]
FP 4” Intake [5" K&N]
HKS SSQV BOV

TURBO:
FP Green UHF 57S
- Compressor: 52.6MM Inducer / 73MM Exducer + 84MM Cover [73HTZ]
- Turbine: 64MM Inducer / 57MM Exducer 8CM Housing [Xona 57s]
- Externally Gated

EXHAUST:
FP Exhaust Manifold
STM SS recirculated o2 Housing w/ TiAl Wastegate
Megan Racing 3” Downpipe
3" Fujitsubo Legaris R [JDM]
Granatelli Electric Exhaust Cutout

FUEL:
[FlexFuel]
FIC 1440CC
FIC Fuel Rail [-6an]
Fuel Lab Fuel Pressure Regulator
Radiant Engineering Fuel pulse Damper
Fuel Lab Fuel Filter [40 Micron]
Walbro 450LPH Fuel Pump [Rewired]

OTHER:
Mishimoto Catch Cans [x2]
External Oil Cooler
JEGS Scirocco/Pro Stock Radiator
- 12” SPAL Puller 1600 CFM
IR Electric Boost Controller
.
Mods-Drivetrain
TRE Built 4 Bolt Rear Diff
TRE Built Transfer Case
TRE Built W5M33 Transmission:
- Evo 3 Input Shaft and First Gear
- Pre 1990 Synchro Upgrade
- 4 Spider Center Diff.
- Glass Bead Service, Gear Detail: Corner Rounding, Lead Edge Trim Back, Tip Relief, Engagement Teeth Profiling, Synchro Cone Modification, Modified Gear Stack Offsets, Shift Rail & Selector Modification. Double Saturation, Shot Peening of Gearset and Shift Rails.

South Bend Kevlar Clutch [K05048-SS-TZ]
ACT Streetlight Flywheel
.
Mods-Engine
1G 7-Bolt Head
- HKS 280/280 Cams
- Supertech Black Nitride Valves
- Kiggly Beehive Springs
- Manganese Valve Guides
- Kiggly HLA Regulator
- GSC Zero Tick Lifters

Cometic MLS Head Gasket
ARP Head Studs

2.4L 6 Bolt Block [G4CS]
- Manley Pistons [9:1]
- Eagle 5.900 Forged H Beam Connecting Rods
- Fluidampr Crank Pulley
- Balance Shaft Delete
- Jay Racing Alternator Relocate [Saturn 160 Amp]

.
Mods-EMS/Tuning
ECMLink v3 [Full]
Dash:
- Prosport Oil Pressure
- Prosport Water Temp
- Prosport Volts
A pillar:
- Glowshift Boost
- Innovate LC-2 Wideband

.
Mods-Handling
Volk Curved Rear Upper Control Arms
Whiteline 26mm Rear Sway Bar
3SX Rear 4WS Delete Kit
Bilstein Shocks [Evo MR]
Swift Spec-R Springs
Tein Camber Plates
R1 Concepts Rotors, PowerStop pads
ABS Delete Kit w/ Stainless Lines, Non ABS Prop Valve
Boosted Fab Billet Timing Mount [Poly Insert]
Prothane Poly Motor Mounts

.
